iKAGOO Firmware Support Guide

Hướng dẫn cập nhật qua USB cho cụm đồng hồ LCD: Tải về phiên bản firmware chính xác, tránh tình trạng màn hình đen

Điều này LCD instrument cluster USB update guide explains how to update an iKAGOO digital cluster safely, request the correct firmware, prepare a FAT32 USB drive, place the gor.tar file correctly, avoid PO/MOB platform mismatch, and fix black screen, boot loop or failed update problems.

Lưu ý quan trọng: Do not use random firmware files from forums, other sellers or another vehicle. LCD cluster firmware depends on the hardware platform, model version and order batch. Wrong firmware may cause black screen, boot loop, stuck logo or failed update.
Get the Correct Firmware Before Updating Fix Black Screen or Failed Update
LCD instrument cluster USB update guide for iKAGOO digital cluster firmware

Use only official iKAGOO firmware matched to your exact unit.

USB Format FAT32 by default
Firmware File gor.tar in USB root
Platform Rule PO and MOB cannot be mixed
Update Risk Wrong firmware may cause black screen

Firmware Download

Where Is the Firmware Download Link for This LCD Instrument Cluster USB Update Guide?

We do not publish one universal firmware download link because LCD instrument clusters use different hardware platforms, screen versions and software batches. A package that works on one unit may damage another unit.

To receive the correct firmware package, iKAGOO support must first check your order number, current version and back label information.

Send These Details Before Updating

  • Số đơn hàng
  • Mẫu xe và năm sản xuất
  • Current version photo from Cài đặt → Giới thiệu
  • Back label photo of the LCD instrument cluster
  • Problem video if the unit has black screen, boot loop, stuck logo or update failure
Request Official Firmware Support

Quick Summary

LCD Instrument Cluster USB Update Guide: Key Rules Before You Start

  • Format the USB drive to FAT32 by default.
  • Place the final firmware file in the USB root directory.
  • The final update file must be named exactly gor.tar.
  • PO và MOB firmware files are not interchangeable.
  • The update usually takes 3–10 minutes depending on file size, hardware platform and update stage.
  • Do not remove the USB drive or cut power during the update.

Trước khi bắt đầu

Check the LCD Instrument Cluster Before Updating

If this is a new installation, finish the physical installation and compatibility check before firmware flashing. For VW and Audi models, review the Audi VW digital cluster installation guide và VW Audi digital instrument cluster user manual before changing firmware.

  1. Confirm the exact product version. Check your order information or go to Cài đặt → Giới thiệu to identify the current software, MCU or UI version.
  2. Use only the official package for your unit. Do not use firmware from another seller, another vehicle, or another iKAGOO order unless support confirms it is compatible.
  3. Verify the final file name. The update file must be gor.tar. Extra names such as gor.tar.zip, gor.tar(1), GOR.TAR hoặc gor (1).tar are not acceptable.
  4. Keep stable power. Battery voltage should stay above 12.2V. A power maintainer is recommended. If the engine is running, keep the vehicle in a safe and ventilated area.
  5. Take photos before updating. Save photos of the current version page, CAN settings, language, units and theme settings.

USB Preparation

Prepare FAT32 USB for the LCD Instrument Cluster USB Update

  1. Use a reliable USB drive, preferably 8–32GB.
  2. Format the USB drive to FAT32 with default allocation size.
  3. Extract the downloaded firmware package if it is compressed.
  4. Copy the final gor.tar file to the USB root directory.
  5. Do not place gor.tar inside any folder.
  6. Safely eject the USB drive before inserting it into the vehicle.
Correct: USB drive → gor.tar
Wrong: USB drive → folder → gor.tar

Critical Firmware Rules

gor.tar Firmware Rules: Avoid Wrong Firmware and Black Screen

1. File Name Must Be Exact

The final firmware file must be named gor.tar, all lowercase, without extra spaces, numbers or extensions.

2. USB Root Only

The cluster will usually detect the file only when gor.tar is placed directly in the USB root directory.

3. PO and MOB Cannot Be Mixed

PO and MOB firmware files may use the same gor.tar file name, but they are not interchangeable. Cross-flashing the wrong platform may cause no-boot, black screen or stuck logo.

4. Version Check Comes First

Before updating, compare the current version in Cài đặt → Giới thiệu with the update package information supplied by iKAGOO support.

Update Procedure

Run the LCD Instrument Cluster USB Update

VW/Audi owner? If your unit is a Volkswagen or Audi digital cluster, read the VW/Audi digital instrument cluster online and USB update guide first. Some units may use online update logic before USB flashing.
  1. 1
    Turn ignition to ACC/ON. Wait until the digital cluster fully boots.
  2. 2
    Insert the USB drive into the cluster service USB port. Do not use the head unit media USB port unless iKAGOO support specifically tells you to.
  3. 3
    Open the update menu. Truy cập Settings → System → Update → USB Update. Some units may auto-detect the update file.
  4. 4
    Confirm the update. The screen may go black, restart, or show no visible progress during some stages. This can be normal.
  5. 5
    Wait until the update is complete. Do not remove USB or cut power during the update.
  6. 6
    Restart correctly. When prompted, remove the USB drive, power off the vehicle, lock the car for about 3 minutes, then restart and check the version.

After Update

Post-Update Checklist for Your LCD Instrument Cluster

  • Check the new software version in Cài đặt → Giới thiệu.
  • Restore language, units, timezone and theme settings if needed.
  • Re-select CAN protocol if the unit has reset to default settings.
  • Test steering wheel controls, indicators, warning icons and TPMS display if supported.
  • Test speed, RPM, fuel level or EV battery information.
  • Take a short test drive only after the display and vehicle data appear normal.

Problem Solving

LCD Instrument Cluster USB Update Troubleshooting

USB drive is not detected
  • Reformat the USB drive to FAT32.
  • Use a smaller USB drive, preferably 8–32GB.
  • Make sure the file is named exactly gor.tar.
  • Place gor.tar in the USB root directory.
  • Try the cluster service USB port instead of the media USB port.
Version mismatch or update rejected
  • The firmware may not match your hardware platform or software batch.
  • Do not force the update.
  • Send your version photo and back label photo to iKAGOO support.
Black screen after update
  • Keep stable power for 10–15 minutes. Some update stages may be silent.
  • If the unit still does not boot, do not repeatedly try random firmware.
  • Contact iKAGOO support with a short problem video, version photo if available, and back label photo.
Stuck on logo or boot loop
  • This may be caused by wrong firmware, interrupted power or platform mismatch.
  • Prepare a clean FAT32 USB drive with only the correct gor.tar.
  • Ask iKAGOO support to confirm whether your unit is PO, MOB or another platform before reflashing.
Settings disappeared after update
  • Major updates may reset language, units, themes and CAN settings.
  • Re-apply your saved settings from the photos taken before updating.
Can I downgrade the firmware?
  • No, not unless iKAGOO support confirms that downgrade is allowed for your exact hardware version.
  • Mixing MCU, UI or platform files may create unstable behavior.

Support Materials

What to Send iKAGOO Support Before a Firmware Update

If the update fails or you need the correct firmware package, send clear information first. This reduces wrong diagnosis and avoids unnecessary firmware risk.

Bắt buộc

  • Số đơn hàng
  • Mẫu xe và năm sản xuất
  • Current version photo
  • Back label photo

If There Is a Problem

  • Short video of the issue
  • Photo of USB file structure
  • Photo of the USB port used
  • Description of what happened before failure
Liên hệ với bộ phận hỗ trợ của iKAGOO

Câu hỏi thường gặp

LCD Instrument Cluster USB Update Guide FAQ

Where is the firmware download link?

We do not publish one universal firmware file. The correct package depends on your LCD cluster platform, model version and order batch. Contact iKAGOO support with your order number, version photo and back label photo to receive the correct file when available.

Can I use firmware from another seller?

No. Firmware from another seller, another vehicle or another batch may not match your hardware platform. Wrong firmware can cause black screen, boot loop or failed update.

What file system should I use for this LCD instrument cluster USB update guide?

Use FAT32 by default. Use another file system only if iKAGOO support or the official release note specifically requires it.

Where should I place the gor.tar firmware file?

Place gor.tar directly in the USB root directory. Do not put it inside any folder.

How long does the LCD instrument cluster USB update take?

Usually 3–10 minutes depending on firmware size, hardware platform and update stage. Some phases may show a black screen or no visible progress. Do not remove the USB drive or cut power.

Tôi có thể sử dụng bất kỳ cổng USB nào không?

No. Use the cluster service USB port. Do not use the head unit media USB port unless iKAGOO support confirms that it is correct for your unit.

What should I do if the update fails?

Stop trying random firmware. Send iKAGOO support your order number, vehicle model, version photo, back label photo, USB file structure photo and a short problem video.

Will I lose my settings after updating?

Minor updates usually keep settings, but major updates may reset language, units, themes or CAN settings. Take photos before updating so you can restore them later.
